360A HDTV Antena

360° HDTV OMNIDIRECTIONAL ANTENNA

High Performance TV Signal Reception Model No. EZ-360A-HDTV

Easy to install, Compact Size & Light Weight FIT MOST EXISTING MOUNTS • Easy to install, compact size and light weight

• Compatible with HDTV and ATSC digital terrestrial signal DAB/FM radios.

• Waterproof housing design made of UV resistant material for superior durability.

• Omnidirectional antennas receive VHF, UHF and FM signal from every point regardless of the direction you are traveling.

• Built-in high gain and low noise amplifier, shielded for minimum interference.

• Omnidirectional antenna surface is treated to withstand hail impact during sever weather conditions.

• The best digital terrestrial TV reception solution for RV’s, motorhomes, caravans or boating.

TECHNICAL SPECIFICATIONS Frequency range: FM: 87.5-5-108MHz VHF: 174-230MHz Max. output level: 110dB V UHF: 470-862MHz Impedance: 75 Channels” FM/5-12/21-69 Connector: F-connectors Gain: 30dB Power supply: DC 12V 150mA Noise Figure: 2.5dB The range for typical Omni-Directional antennas is 60-65 miles, though this can vary depending upon outside obstructions. The Antenna has a internal 12V power booster built into it, so you have to ensure your coaxial cable is a "powered" cable which runs through a power source.
